NanoCool™ Cooling Systems
Our Original Solution, Still Leading the Way: The tried-and-true, original temperature-controlled refrigerated system NanoCool™ Cooling Systems continues to set the industry standard with effortless cooling at the push of a button.
Relying on our advanced evaporative cooling technology, NanoCool Cooling Systems are designed to deliver reliable thermal protection for 48 to 96 hours, specifically for 2°C to 8°C shipments. Compact and lightweight, NanoCool Cooling Systems minimize freight costs and save valuable warehouse space, making them the trusted choice for secure, efficient transport of your sensitive products.
If you need extra protection? Upgrade to NanoCool Universal Systems to boost thermal performance and reduce thermal excursion risk. (Click here to find out more)
Purchase Only
1-8L
1 temperature option
- 2C to 8C
40H to 72H (30°C) to 48H to 120H (20°C)
Single use parcel
1-8L
1 temperature option
2C to 8C
48 - 96 hours (Extreme)
Qualified to ISTA 7D profiles, option to downgrade to NanoCool Shuttle to save cost if shipped on a more typical or controlled lane
Why choose NanoCool™ Cooling?
- Evaporative CoolingOn-demand conditioning saves on freezer space and cost
- UN3373 compatibleFits inside overnight UN3373 designated envelopes
- Error-proof assemblySimple, one-touch activation removes box preparation errors
- Lightweight to ShipReduce transportation costs loading more per pallet than bulky single use EPS solutions
- Less product riskEliminating the need for product replacement after a thermal excursion event
NanoCool™ Cooling Systems Product Tour
product
High Quality VIP / Foam Insulation
We prioritize payload and patient protection, maximizing thermal performance and stability throughout the complete cold chain journey.
product
Fast and Simple Coolant Activation
We prioritize the user experience and operational throughput minimizing errors during assembly to ship out in-temperature and on-time.
product
Activate Anywhere When Needed
We prioritize preparation and agility maximizing responsiveness to unpredictable demand without sacrificing product quality.
product
No Gel Packs Required
We save on storage and conditioning costs providing a solution that activates on-demand with no further conditioning required.
Challenges
NanoCool™ Cooling Systems, Single-Use Solution
Traditional Single-Use, Water Based Solution
Temperature sensitivity
Consistent thermal performance that adjusts to variations in ambient temperature in way that traditional water based systems cannot.
Poor temperature stability and little to no performance buffer increases the likelihood of thermal fluctuations in the real world putting cell viability and efficacy at risk.
Packout errors
Simple, one-touch activation can be performed by all operators with little to no training without the need for any conditioning equipment or space.
Managing countless seasonal packout configurations and packaging options can lead to errors during packout assembly from low skilled or temporary staff resulting in rework or worse temperature excursions in transit.
Balancing Packaging and Freight Cost
Reduced actual, dimensional and billable weight often outweighs the higher price for a better quality solution.
Low upfront prices are often outweighed by high freight, warehouse and excursion costs due to high volumetric weight, poor pallet utilization and low temperature protection.
Unplanned last minute collections
Low storage cost in ambient storage only and ready to deploy quickly in a matter of minutes.
High operational cost to store excess box and coolant safety stock in ambient, refrigerated and frozen storage with no guarantee of use.
Lower CO2 footprint and landfill usage
Lower volumetric weight and risk of temperature excursions significantly reduces the number of planes and trucks required to transport or replace pharma product.
Bulky and high volumetrically weighted boxes increase the amount of transportation required. Single use boxes enter landfill sites in unthinkable quantities each and every day.
NanoCool™ Cooling Systems Specifications
Product Type
[LxWxH]
External Dimensions
[LxWxH]
Internal Dimensions
[LxWxH]
Tare Weight
[kg]
Volumetric Weight
[kg]
Performance Level
[hours]
2-85225 1.05L
307 x 201 x 129
216 x 119 x 41
1.7
1.44
48
2-85228 1.05L
307 x 201 x 129
216 x 119 x 41
1.9
1.44
90
2-85401 2.62L
307 x 201 x 189
216 x 119 x 102
2.3
2.16
48
2-85408 2.62L
307 x 201 x 189
216 x 119 x 102
2.5
2.16
96
2-98601 8.25L
352 x 305 x 262
241 x 221 x 155
4.3
5.46
48
2-98608 8.25L
352 x 305 x 262
241 x 221 x 155
4.9
5.46
92
2-85608 3.85L
307 x 201 x 251
216 x 119 x 150
2.9
3.10
92
Shuttle 2-84121
305 x 200 x 92
190 x 90 x 30
1.1
1.1
40
2-85225 1.05L
12.1 x 7.9 x 5.1
8.5 x 4.7 x 1.6
3.8
3.17
48
2-85228 1.05L
12.1 x 7.9 x 5.1
8.5 x 4.7 x 1.6
4.2
3.17
90
2-85401 2.62L
12.1 x 7.9 x 7.4
8.5 x 4.7 x 4
5.1
4.7
48
2-85408 2.62L
12.1 x 7.9 x 7.4
8.5 x 4.7 x 4
5.5
4.7
96
2-98601 8.25L
13.9 x 12. x 10.3
9.5 x 8.7 x 6.1
9.4
12
48
2-98608 8.25L
13.9 x 12. x 10.3
9.5 x 8.7 x 6.1
10.6
12
92
2-85608 3.85L
12.1 x 7.9 x 9.8
8.5 x 4.7 x 5.9
6.4
6.8
92
Shuttle 2-84121
12.0 x 7.9 x 3.6
7.5 x 3.5 x 1.2
2.4
2.2
40
